S65 Artımlı (Incremental) Enkoder, Döner (Rotational) Enkoder, CW / CCW Yön Algılama, Kare Dalga Çıkışı, 9 Pin Konnektör M18, 10 Pin Konnektör M28, A + B + Z + A− B− Z− Sinyalleri, 5–30 V Besleme Gerilimi

Name: S65 Artımlı (Incremental) Enkoder, Döner (Rotational) Enkoder, CW / CCW Yön Algılama, Kare Dalga Çıkışı, 9 Pin Konnektör M18, 10 Pin Konnektör M28, A + B + Z + A− B− Z− Sinyalleri, 5–30 V Besleme Gerilimi
Brand: OLVO
SKU: T1529
Availability: InStock

Ürün Kodu: T1529

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	SURAL
Encoder type	Incremental encoder
External diameter	65mm
Thickness	53mm
Installation dimension	Diameter 48mm
Shaft length	16mm
Solid Shaft diameter	8mm(D shape)
Resolution	50; 60; 100; 200; 250; 256; 300; 360; 400; 450; 500; 512; 600; 720; 1000
	1000; 1024; 1200; 1250; 1440; 1800; 2000; 2048; 2500; 2880; 3000
	3600; 4000; 4096; 5000; 5760; 8192; 10000; 11520; 16384; 20000; 23040
Output phase	Phase A+, B+, Z+, A- B- Z-
Supply voltage	DC5V; DC8~30V
Housing color	Black
Outlettype	Radial cable
	Radial socket
Output mode	Collector open circuit output
	Voltage output
	Push-pull output
	Difference output	Long line drive (26LS31)
		Compatible RS422
		Long line drive (RT7272)
Protection grade	IP50; IP65
Cable length	1M(cable length could be added appropriately by
	Require, but it need payment individually)
Consumption current	100mA MAX
Top response frenquency	300KHZ
Allowable ripple	≤3%rms
Load Voltage	≤DC30V
Insulation strength	AC500V 60s
Insulation resistance	10MΩ
GND	Not connect to encoder
Mark to Space ratio	45% to 55%
Starting torque	Less than 5x 10-3 N.m
Intertia moment	Less than 3x 10-6kg.m2
Shaft load	Radial 50N; Axial 30N
Top REV	5000RPM; IP65≤3000r rpm
Bearing life	1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature	Operating: -20 ~ +80°; storage: -25 ~ +85°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Vibration(endure)	Amplitude 0.75mm, 5-55Hz, 2 hours for three axis individually
Sock(endure)	490m/s2, 11 ms three times for X, Y, Z direction individually
Shaft Material	Stainless steel
Shell Material	Dia cast aluminium
Cable length	1000mm(cable with shielding)
Certification	CE
Package	Carton box
Net weight	About 350g (with package)
