OLV-K58 incremental encoder, rotary encoder 58 mm dış çap, 24 mm kalınlık Kolay montajlı enkoder 28.800 pulse’a kadar çözünürlük

Name: OLV-K58 incremental encoder, rotary encoder 58 mm dış çap, 24 mm kalınlık Kolay montajlı enkoder 28.800 pulse’a kadar çözünürlük
Brand: OLVO
SKU: T3192
Availability: InStock

Ürün Kodu: T3192

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	OLVO
Encoder type	Incremental encoder
External diameter	58m
Thickness	24mm
Installation dimension	R34.1mm(spring plate 58T64)
Hollow shaft type	clamping ring at rear or clamping ring at prior
Hollow shaft diameter	15mm/16mm/18mm/20mm/22mm
Resolution	1000;1024;1200;1250;1440;2000;2048;2500;5000；7200；14400；28800
	1000/4;1000/6;1000/8;1024/4;1024/6;1024/8;2048/4;2048/6;2500/4；2500/6；2500/8


Output phase	Phase A+, B+, Z+, A-, B-, Z-, U+, V+, W+, U-, V-, W-
Supply voltage	DC5V ; DC8-30V
Outlettype	Cable out from side


Output mode	NPN/PNP(Open Collector Output)
	Voltage output
	Push-pull output
	Line drive (26LS31) TTL
	Line drive(DC8-30V) HTL
	TTL(DC5V) phase ABZ are back of phase UVW
Consumption current	100mA MAX
Top response frenquency	300KHZ
Allowable ripple	≤3%rms
Load Voltage	≤DC30V
GND	not connect to encoder
Mark to Space ratio	45% to 55%
Starting torque	Less than 9.8 x 10-3 N.m
Intertia moment	Less than 6.5x 10-6kg.m2
Shaft load	Radial 50N; Axial 30N
Top REV	3000RPM
Bearing life	1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature	Operating: -20~+80°; storage: -25~+85°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Vibration(endure)	Amplitude 1.52mm, 5-55Hz, 2 hours for three axis individually
Sock(endure)	490m/s2, 11 ms three times for X, Y, Z direction individually
Shaft Material	Stainless steel
Shell Material	Dia cast aluminium
Cable length	1000mm(cable with shielding)
Protection grade	IP50;
Cable length	1M (cable length could be added appropriately by Eequire, but it need payment individually)

Certification	CE
Package	Carton box
Net weight	About 150g (with package)
