OLV-K52 incremental encoder, radial M18 konnektörlü hollow shaft rotary encoder Endüstriyel enkoder Mil çapı: 14 mm Kalınlık: 39 mm 5 pin rotary encoder (motor uygulamaları için)

Name: OLV-K52 incremental encoder, radial M18 konnektörlü hollow shaft rotary encoder Endüstriyel enkoder Mil çapı: 14 mm Kalınlık: 39 mm 5 pin rotary encoder (motor uygulamaları için)
Brand: OLVO
SKU: T3193
Availability: InStock

Ürün Kodu: T3193

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	OLVO
Encoder type	Incremental encoder
External diameter	51mm
Thickness	39mm
Installation dimension	R27.5mm(spring plate 50T55)
Hollow shaft type	Through hole or blind hole
Hollow shaft diameter	8mm,10mm,12mm;14mm;15mm
Resolution	1000;1024;1200;1250;1440;2000;2048;2500;2880;3000;3600
	4096;5000;5760;8192;10000；11520；16384；20000；23040
	1000/4; 1000/6; 1000/8; 1024/4; 1024/6; 1024/8; 2048/4; 2048/6
	2048/8; 4096/4; 4096/6; 4096/8; 8192/4; 8192/6; /8192/8
Output phase	Phase A+, B+, Z+, A-, B-, Z-, U+, V+, W+, U-, V-, W-
Supply voltage	DC5V; DC8-30V
Outlettype	Cable out from back
	Socket out from back
	Cable out from back with socket
Output mode	NPN/PNP(Open Collector Output)
	Voltage output
	Push-pull output
	Line drive (26LS31) TTL
	Line drive(DC8-30V) HTL
	TTL(DC5V) phase ABZ are back of phase UVW
Consumption current	100mA MAX
Top response frenquency	300KHZ
Allowable ripple	≤3%rms
Load Voltage	≤DC30V
GND	Not connect to encoder
Mark to Space ratio	45% to 55%
Starting torque	Less than 9.8 x 10-3 N.m
Intertia moment	Less than 6.5x 10-6kg.m2
Shaft load	Radial 50N; Axial 30N
Top REV	3000RPM; IP65≤2000r rpm
Bearing life	1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature	Operating: -20~+80°; storage: -25~+85°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Vibration(endure)	Amplitude 1.52mm, 5-55Hz, 2 hours for three axis individually
Sock(endure)	490m/s2, 11 ms three times for X, Y, Z direction individually
Shaft Material	Stainless steel
Shell Material	Dia cast aluminium
Cable length	1000mm(cable with shielding)
Protection grade	IP50; IP65
Cable length	1M (cable length could be added appropriately by require, but it need payment individually)

Certification	CE
Package	Carton box
Net weight	About 310g (with package)
