Gelince Haber Ver| Items | Basic parameters |
| Brand | SURAL |
| Encoder type | Incremental encoder |
| External diameter | 50mm |
| Thickness |
18.5mm |
| Hollow shaft type | Through hole |
| Hollow shaft diameter | 10mm;12mm;14mm;15mm(optional) |
| Resolution | 1000; 1024; 1250; 2000; 2048; 2500; 4096; 5000; 10000 |
| Output phase | Phase A+, B+, Z+, A-, B-, Z-, U+, V+, W+, U-, V-, W- |
| Supply voltage | DC5V; DC8--30V |
| Outlet type | Cable out from side |
| Output mode | Line drive (26LS31)TTL |
|
Line drive(DC8-30V)HTL Push-pull |
|
| Cable length | 1000mm |
| Consumption current | 100mA Max; 120mA Max |
| Top response frenquency | 100kHZ; 500kHZ; 600kHZ |
| GND | not connect to encoder, must be effectively connected to GND |
| Slew speed | ≤5000rpm |
| Environmental temperature | Operating: -40~+90℃(repeatable winding cable: -10℃); Storage: -45~+95℃ |
| Enviromental humidity | Operating and storage: 50-85%RH(noncondensing) |
| Material | Stainless steel |
| Protection Grade | IP67 |
| Ppackage |
Carton box |
| Net weight | About 150g |
