OLV-S18 Artımlı (Incremental) Enkoder, Düşük Maliyetli Döner (Rotary) Enkoder, 18 mm Miniyatür Döner Enkoder, ABZ Faz Çıkışlı, NPN Çıkış, 1600 PPR’a Kadar Çözünürlük, Subminyatür Motorlar İçin Uygun

Name: OLV-S18 Artımlı (Incremental) Enkoder, Düşük Maliyetli Döner (Rotary) Enkoder, 18 mm Miniyatür Döner Enkoder, ABZ Faz Çıkışlı, NPN Çıkış, 1600 PPR’a Kadar Çözünürlük, Subminyatür Motorlar İçin Uygun
Brand: OLVO
SKU: T1525
Availability: InStock

Ürün Kodu: T1525

Teklif

PaylaşKoleksiyonFiyat Alarmı

Brand	SURAL
External dimensions	External diameter: 18mm
	Thickness: 18mm
	Solid Shaft Diameter: ⌀2.5mm
Resolution	36; 50; 60; 100; 200; 250; 256; 360; 400; 500; 512; 720; 800; 1000; 1024; 1440; 1600
Output phase	Phase A, B, Z
Supply voltage	DC5V; DC8-30V
Outlettype	Cable out from side
	Cable out from back
Output mode	Collector open circuit output(NPN&PNP)
Environmental temperature	Operating temperature: -20~+80°(Non icing)
	Storage temperature: -25~+85°(Non icing)
Environmental humanity	Operating and storage: 35~85%RH(non-condensing)
Top Resonse Frequency	100kHz Max
Top Rev	5000rpm
Protection grade	IP50
Consumption current	50mA Max
Rise/ Fall time	100nsec Max
Shaft Load	Radial: 2N; Axial: 2N
Vibration(endure)	Amplitude 0.75mm, 10-50Hz, 1 hour for X/Y/Z direction individually
Shock(endure)	49/m/s2, three times for X, Y, Z direction individually
Shaft Material	304 stainless steel
Cable length	150mm
Shell	Aluminium Alloy
Package	Carton box
Net weight	About 20g (with package)
Certification	CE
