OLV-KSN19 Mikro / Miniyatür Artımlı (Incremental) Enkoder, 3 mm Mil Çapı, 100 – 13684 PPR Çözünürlük Aralığı

Name: OLV-KSN19 Mikro / Miniyatür Artımlı (Incremental) Enkoder, 3 mm Mil Çapı, 100 – 13684 PPR Çözünürlük Aralığı
Brand: OLVO
SKU: T1521
Availability: InStock

Ürün Kodu: T1521

Teklif

PaylaşKoleksiyonFiyat Alarmı

Brand	SURAL
Encoder type	Incremental encoder
External diameter	19mm
Thickness	18.5mm
Hollow shaft diameter	3mm
Resolution	100;250;256;360;400;500;512；720；800；1000;1024；1440;1600;2000;2880;4000;5760;8000;11520;16000; 2048;3200;4096;6400;8192;12800;16384
Output phase	Phase A,B,Z
Supply voltage	DC5V ; DC8-30V
Output mode	HTL/TTL
Protection grade	IP50
Cable length	1M (cable length could be added appropriately by
Cable length	require, but it need payment individually)
Consumption current	50mA MAX
Top response frenquency	100KHZ
Rise/ Fall time	100nsec Max
starting torque	less than 5x 10-4 N.m
Intertia moment	less than 0.3x 10-6kg.m2
Shaft load	Radial 2N; Axial 2N
Top REV	6000r rpm
Environmental temperature	Operating:-20 ～+85°；storage:-80 ～+85°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Vibration(endure)	Amplitude 0.75mm,10-50Hz,1 hours for three axis individually
Sock(endure)	49m/s2 ,three times for X,Y,Z direction individually
Shaft Material	Stainless steel
Shell Material	aluminium alloy;304
Cable length	150mm
Certification	CE
package	Carton box
Net weight	About 26g (with package)
