Gelince Haber Ver| Items | Basic parameters |
| Brand | SURAL |
| Encoder type | Incremental encoder |
| External diameter | 16mm |
| Thickness | 22.4-25.4mm |
| Hollow shaft diameter | 3mm blind hole |
| Resolution | 160;250;256;300,360;320,500;512;600;640;720;1000;1024;1200;1280;1440;2000;2048;2400;2560;4000;4800;5120;5760;8000;8192;9600;11520 |
| Output phase | Phase A,B,Z |
| Supply voltage | DC5V ; DC8-30V |
| Outlettype | Radial cable |
| Axial cable | |
| Radial cable with conector | |
| Output mode | TTL /HTL |
| Protection grade | IP50 |
| Cable length | 1M (cable length could be added appropriately by |
| require, but it need payment individually) | |
| Consumption current | 100mA MAX |
| Top response frenquency | 300-500KHZ |
| Rise/ Fall time | 100nsec Max |
| Shaft load | Radial 2N; Axial 2N |
| Top REV | 6000r rpm |
| Environmental temperature | Operating:-20 ～+80°；storage:-80～+85° |
| Enviromental humidity | Operating and storage: 35-95%RH(noncondensing) |
| Shaft Material | Stainless steel |
| Shell Material | aluminium alloy |
| Certification | CE |
| package | Carton box |
| Net weight | About 20g (with package) |
