K130 Artımlı (Incremental) Enkoder, Totem Pole Çıkışlı, Asansör Enkoderi, İçi Boş Mil (Hollow Shaft), 48 / 55 / 60 mm Mil Çapı, Maks. 0,05 mm Eksen Kaçıklığı (Concentricity), Maks. 130 mm Dış Çap, 1700 gram, CNC Uygulamaları İçin Enkoder

Name: K130 Artımlı (Incremental) Enkoder, Totem Pole Çıkışlı, Asansör Enkoderi, İçi Boş Mil (Hollow Shaft), 48 / 55 / 60 mm Mil Çapı, Maks. 0,05 mm Eksen Kaçıklığı (Concentricity), Maks. 130 mm Dış Çap, 1700 gram, CNC Uygulamaları İçin Enkoder
Brand: OLVO
SKU: T1538
Availability: InStock

Ürün Kodu: T1538

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	OLVO
Encoder type	Incremental encoder
External diameter	130mm
Thickness	48mm
Installation dimension	R72.5mm(spring plate 130T145)
Hollow shaft type	through hole (clamping ring at prior)
Hollow shaft diameter	48mm,55mm,60mm;
Resolution	1024;2048;4096;8192;16384;32768;65536



Output phase	Phase A+,B+,Z+,A-,B-,Z-
Supply voltage	DC5V; DC8-30V
Outlettype	cable out from side


Output mode	HTL


	TTL,RS422
Consumption current	100mA MAX
Top response frenquency	300KHZ
Allowable ripple	≤3%rms
Load Voltage	≤DC30V
GND	Not connect to encoder
Mark to Space ratio	45% to 55%
starting torque	less than 300 x 10-3 N.m
Intertia moment	less than 220x 10-6kg.m2
Shaft load	Radial 90N; Axial 60N
Top REV	3000RPM;
Bearing life	1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature	Operating:-20 ～+85°；storage:-25 ～+90°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Vibration(endure)	Amplitude 1.52mm,5-55Hz,2 hours for three axis individually
Sock(endure)	1960m/s2 ,11 ms three times for X,Y,Z direction individually
Shaft Material	Stainless steel
Shell Material	aluminium alloy
Cable length	1000mm(cable with shielding)
Protection grade	IP50;
Cable length	1M(cable length could be added appropriately by Require, but it need payment individually)

Certification	CE
Package	Carton box
Net weight	About 1700g (with package)
