OLV-KM16 Kör Milli (Blind Shaft) 3 mm Miniyatür Mutlak (Absolute) Enkoder, 10-bit – 20-bit, Tek Tur (Single-turn) ve Çok Tur (Multi-turn)

Name: OLV-KM16 Kör Milli (Blind Shaft) 3 mm Miniyatür Mutlak (Absolute) Enkoder, 10-bit – 20-bit, Tek Tur (Single-turn) ve Çok Tur (Multi-turn)
Brand: OLVO
SKU: T1542
Availability: InStock

Ürün Kodu: T1542

Teklif

PaylaşKoleksiyonFiyat Alarmı

Brand	OLVO
Encoder type	Absolute encoder
External diameter	16mm
Thickness	22.4-25.4mm
Installation type	with or without spring plate
Installation dimension	11mm
Hollow shaft type	Blind hole
Hollow shaft diameter	3mm
Resolution	single-turn:10-20Bit
Resolution	multi-turn: 16Bit Max
Communication	BISS-C; SSI
Electrical connection	Radial cable
Output mode	Multi-turn(Binary&Gray)
Output mode	Single-turn(Binary&Gray)
Scanning principle	Photoelectric
Accuracy	±80"
Response speed	Normal action: 6000min
RMS position signal noise	±2@18 bits/r
Communication clock frequency	≤10MHz(BISS) or ≤ 5MHz(SSI)
Starting time	typical value: 13ms
Absolute position sampling period	≤75 ns
Allowable speed	≤32200 r/min (restricted by mechanical speed limit)
Shaft load	Radial 2N; Axial 2N
Slew speed	≤6000rpm
Shell Material	Aluminum
Weight	about 25g
Environmental temperature	Operating: -40~+85℃; Storage: -40~+85℃
Environmental humidity	Operating and storage: 35~85%RH(Noncondensing)
Protection	IP50/ IP65
