OLV-K158 Artımlı (Incremental) Enkoder, Geçmeli Delik (Through Hole), 70 / 75 / 78 / 80 / 82 mm İçi Boş Mil, 43 mm Kalınlık, Alüminyum Alaşım Gövde, IP50 Koruma Sınıfı, Yüksek Hassasiyetli Enkoder

Name: OLV-K158 Artımlı (Incremental) Enkoder, Geçmeli Delik (Through Hole), 70 / 75 / 78 / 80 / 82 mm İçi Boş Mil, 43 mm Kalınlık, Alüminyum Alaşım Gövde, IP50 Koruma Sınıfı, Yüksek Hassasiyetli Enkoder
Brand: OLVO
SKU: T1537
Availability: InStock

Ürün Kodu: T1537

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	OLVO
Encoder type	Incremental encoder
External diameter	158mm
Thickness	43mm
Installation dimension	R85mm(spring plate 158T170)
Hollow shaft type	through hole (clamping ring at prior)
Hollow shaft diameter	70mm,75mm,78mm;80mm;82mm
Resolution	1024;2048;20000;40000;80000



Output phase	Phase A+,B+,Z+,A-,B-,Z-
Supply voltage	DC5V; DC8-30V
Outlettype	cable out from side


Output mode	HTL


	TTL,RS422
Consumption current	100mA MAX
Top response frenquency	300KHZ
Allowable ripple	≤3%rms
Load Voltage	≤DC30V
GND	Not connect to encoder
Mark to Space ratio	45% to 55%
starting torque	less than 400 x 10-3 N.m
Intertia moment	less than 350x 10-6kg.m2
Shaft load	Radial 90N; Axial 60N
Top REV	3000RPM;
Bearing life	1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature	Operating:-20 ～+85°；storage:-25 ～+90°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Vibration(endure)	Amplitude 1.52mm,5-55Hz,2 hours for three axis individually
Sock(endure)	1960m/s2 ,11 ms three times for X,Y,Z direction individually
Shaft Material	Stainless steel
Shell Material	aluminium alloy
Cable length	1000mm(cable with shielding)
Protection grade	IP50;
Cable length	1M(cable length could be added appropriately by Require)

Certification	CE
Package	Carton box
Net weight	About 1800g (with package)
