Items
|
Basic parameters
|
|
Brand
|
OLVO
|
|
Encoder type
|
Absolute encoder
|
|
External diameter
|
55mm
|
|
Thickness
|
22mm
|
|
Installation dimension
|
60±0.1mm diameter
|
|
Shaft type
|
Through shaft
|
|
Shaft diameter
|
14mm; 20mm; 22mm; 24mm; 25mm
|
|
Bit(steps)
|
Single-turn 17bits; 19bits; 20bits; 22bits; 24bits;Up to 32bits; Multi-turn: 16bits+(17-26bits)
|
|
Outlet type
|
Radial cable; Radial socket
|
|
Electrical interface
|
RS-485
|
|
Communication
|
BISS C (Binary)
|
|
SSI (Binary/Gray)
|
|
|
Protection grade
|
IP50
|
|
Cable length
|
1M (cable length could be added appropriately by
|
|
require, but it need payment individually)
|
|
|
Response speed
|
Normal action: 6000min-1
|
|
RMS position signal noise
|
±2 @18 Bits/r
|
|
Communication clock frequency
|
≤10 MHz (BiSS) or ≤5 MHz (SSI)
|
|
Starting time
|
Typical value: 13ms
|
|
Absolute position sampling priod
|
≤75 ns
|
|
Mechanical connection
|
Ring locking with shaft, flexible spring plate fixed connection
|
|
starting torque
|
less than 9.8x 10-3N.m
|
|
Intertia moment
|
less than 6.5x 10-6kg.m2
|
|
Shaft load
|
Radial 30N; Axial 20N
|
|
Allowed speed
|
≤6000r rpm
|
|
Environmental temperature
|
Operating:-20 ～+95°C；storage:-25 ～+95°C
|
|
Enviromental humidity
|
Operating and storage: 35-85%RH(noncondensing)
|
|
Vibration(endure)
|
Amplitude 1.52mm,5-55Hz,2 hours for three axis individually
|
|
Shock(endure)
|
980m/s2 ,11 ms three times for X,Y,Z direction individually
|
|
Shaft Material
|
Stainless steel
|
|
Shell Material
|
Aluminum alloy
|
|
Certification
|
CE
|
|
package
|
Carton box
|
|
Net weight
|
About 150g (with package)
|
